OpenSSL is an open source tool and cryptographic library that implements the SSL (Secure Sockets Layer) and TLS (Transport Layer Security) protocols. OpenSSL is an independent project maintained by volunteers from all over the world. In short, OpenSSL provides a cryptographic tool for securing network connections. A common implementation of SSL is to secure web pages with HTTPS (HyperText Transfer Protocol secured with encryption). OpenSSL encryption over the HTTP protocol consists of the following steps:
- An HTTP client (web browser) sends an HTTPS request to a web server.
- The server responds by sending an SSL Certificate to the client containing the public key, domain name, and issuing SSL certificate authority.
- The client sends a message encrypted using the server's public SSL key.
- The server decrypts this message with its private SSL key.
- The server finally sends the decrypted message back to the client.
- If the client receives the correct message, both parties can begin to exchange information securely, assuming the issuing certificate authority is trusted by the client.
OpenSSL provides the tools needed to create certificate signing requests, private server keys, and self-signed certificates. When combined with a recognized certificate authority, trusted server certificates can be created for use with TCP protocols such as HTTP, SMTP, IMAP, and so on.
OpenSSL is based on the SSLeay library originally developed by Eric A. Young and Tim J. Hudson. SSLeay is an open source implementation of Netscape's Secure Socket Layer protocol, which was used in the Netscape Secure Server and Navigator browsers in the mid-1990s.
OpenSSL is very easy to install on FreeBSD, here's how to install OpenSSL on a FreeBSD system.
root@router2:~ # cd /usr/ports/security/openssl
root@router2:/usr/ports/security/openssl # make DISABLE_VULNERABILITIES=yes install clean
root@router2:/usr/ports/security/openssl # echo "DEFAULT_VERSIONS+=ssl=openssl" >> /etc/make.conf
Before configuring OpenSSL, back up or copy the openssl.cnf file so that if something goes wrong during configuration, the original file is still there.
root@router2:~ # cd /usr/local/openssl
root@router2:/usr/local/openssl # cp openssl.cnf openssl.cnf.backup
Now we can directly modify the openssl.cnf file, but before that check the version of OpenSSL you are using.
root@router2:/usr/local/openssl # openssl version
OpenSSL 1.1.1t-freebsd 7 Feb 2023
1. Create CA Certificate
In this section, SSL Certificate will be created using CA.pl script (Perl script) installed by OpenSSL port. You can create an official certificate to sign your SSL Certificate by sending a request. Certificate authority needs a certificate request file to create a valid SSL Certificate for your server. We will use CA.pl script included with OpenSSL to create certificate request. The following script will copy CA.pl file to /usr/local/openssl/certs folder.
root@router2:~ # cd /usr/local/openssl
root@router2:/usr/local/openssl # cp misc/CA.pl certs
Run the script below to generate a certificate request.
root@router2:~ # cd /usr/local/openssl/certs
root@router2:/usr/local/openssl/certs # setenv OPENSSL /usr/local/bin/openssl
root@router2:/usr/local/openssl/certs # ./CA.pl -newreq
Use of uninitialized value $1 in concatenation (.) or string at ./CA.pl line 133.
====
/usr/local/bin/openssl req -new -keyout newkey.pem -out newreq.pem -days 365
Ignoring -days; not generating a certificate
Generating a RSA private key
..........+++++
...................+++++
writing new private key to 'newkey.pem'
Enter PEM pass phrase:
Verifying - Enter PEM pass phrase:
-----
You are about to be asked to enter information that will be incorporated
into your certificate request.
What you are about to enter is what is called a Distinguished Name or a DN.
There are quite a few fields but you can leave some blank
For some fields there will be a default value,
If you enter '.', the field will be left blank.
-----
Country Name (2 letter code) [AU]:id
State or Province Name (full name) [Some-State]:jawa barat
Locality Name (eg, city) []:bekasi
Organization Name (eg, company) [Internet Widgits Pty Ltd]:mediatama
Organizational Unit Name (eg, section) []:networking
Common Name (e.g. server FQDN or YOUR name) []:router2.unixexplore.com
Email Address []:[email protected]
Please enter the following 'extra' attributes
to be sent with your certificate request
A challenge password []:
An optional company name []:
==> 0
====
Request is in newreq.pem, private key is in newkey.pem
root@router2:/usr/local/openssl/certs #
When creating the certificate above, what needs to be noted is to write "Common Name (eg server FQDN or YOUR name)". In this section we must enter the hostname and domain of our FreeBSD server, in this article "router2" is the hostname and "unixexplore.com" is the domain name.
Running the CA.pl file script above will generate the files "newkey.pem" and "newreq.pem", both files contain encrypted SSL certificates for private servers. For easy identification, copy the file to router2.unixexplore.com-encrypted-key.pem using the following command.
root@router2:/usr/local/openssl/certs # cp newkey.pem router2.unixexplore.com-encrypted-key.pem
root@router2:/usr/local/openssl/certs # cp newreq.pem router2.unixexplore.com-req.pem
The router2.unixexplore.com-encrypted-key.pem file is encrypted with the password you entered earlier. It is important that you remember this password. You will need to enter it whenever an SSL application uses it. If this file is going to be used on an unattended server, it is probably a very good idea to decrypt it, so that the daemon can read it without user intervention. To remove the encryption and create an unencrypted file that is readable only by root, use the following script.
root@router2:/usr/local/openssl/certs # openssl rsa -in router2.unixexplore.com-encrypted-key.pem -out router2.unixexplore.com-unencrypted-key.pem
Enter pass phrase for router2.unixexplore.com-encrypted-key.pem:
writing RSA key
root@router2:/usr/local/openssl/certs # chmod 400 router2.unixexplore.com-unencrypted-key.pem
2. Create a Self-Signed SSL Certificate
One way to create your own certificate is to use the CA.pl file. Note that creating your own certificate will cause the Untrusted Certificate dialog box to appear in application clients (web browsers, email clients, etc.). You can install your server certificate file on the client system to avoid this. Here is a script to create your own 3-year SSL certificate.
root@router2:~ # cd /usr/local/openssl
root@router2:/usr/local/openssl # cp misc/CA.pl certs
root@router2:/usr/local/openssl # sed -I .old 's/365/1095/' openssl.cnf
Run the following script to create your own SSL certificate authority.
root@router2:~ # cd /usr/local/openssl/certs
root@router2:/usr/local/openssl/certs # setenv OPENSSL /usr/local/bin/openssl
root@router2:/usr/local/openssl/certs # ./CA.pl -newca
CA certificate filename (or enter to create)
Making CA certificate ...
====
/usr/local/bin/openssl req -new -keyout ./demoCA/private/cakey.pem -out ./demoCA/careq.pem
Generating a RSA private key
.........+++++
...................+++++
writing new private key to './demoCA/private/cakey.pem'
Enter PEM pass phrase:
Verifying - Enter PEM pass phrase:
-----
You are about to be asked to enter information that will be incorporated
into your certificate request.
What you are about to enter is what is called a Distinguished Name or a DN.
There are quite a few fields but you can leave some blank
For some fields there will be a default value,
If you enter '.', the field will be left blank.
-----
Country Name (2 letter code) [AU]:id
State or Province Name (full name) [Some-State]:jawa barat
Locality Name (eg, city) []:bekasi
Organization Name (eg, company) [Internet Widgits Pty Ltd]:mediatama
Organizational Unit Name (eg, section) []:networking
Common Name (e.g. server FQDN or YOUR name) []:router2.unixexplore.com
Email Address []:[email protected]
Please enter the following 'extra' attributes
to be sent with your certificate request
A challenge password []:
An optional company name []:
==> 0
====
====
/usr/local/bin/openssl ca -create_serial -out ./demoCA/cacert.pem -days 1095 -batch -keyfile ./demoCA/private/cakey.pem -selfsign -extensions v3_ca -infiles ./demoCA/careq.pem
Using configuration from /usr/local/openssl/openssl.cnf
Enter pass phrase for ./demoCA/private/cakey.pem:
Check that the request matches the signature
Signature ok
Certificate Details:
Serial Number:
4b:b7:ad:37:c3:24:ea:c9:62:0a:1b:d5:be:ec:57:4f:e5:94:33:c8
Validity
Not Before: Jun 30 13:17:27 2023 GMT
Not After : Jun 29 13:17:27 2026 GMT
Subject:
countryName = id
stateOrProvinceName = jawa barat
organizationName = mediatama
organizationalUnitName = networking
commonName = router2.unixexplore.com
emailAddress = [email protected]
X509v3 extensions:
X509v3 Subject Key Identifier:
DA:90:FF:39:70:F4:F3:93:E8:CF:29:6E:35:BE:0C:74:EB:38:89:CB
X509v3 Authority Key Identifier:
keyid:DA:90:FF:39:70:F4:F3:93:E8:CF:29:6E:35:BE:0C:74:EB:38:89:CB
X509v3 Basic Constraints: critical
CA:TRUE
Certificate is to be certified until Jun 29 13:17:27 2026 GMT (1095 days)
Write out database with 1 new entries
Data Base Updated
==> 0
====
CA certificate is in ./demoCA/cacert.pem
root@router2:/usr/local/openssl/certs #
To create the above certificate request, use the following command.
root@router2:/usr/local/openssl/certs # ./CA.pl -newreq
Use of uninitialized value $1 in concatenation (.) or string at ./CA.pl line 133.
====
/usr/local/bin/openssl req -new -keyout newkey.pem -out newreq.pem -days 365
Ignoring -days; not generating a certificate
Generating a RSA private key
..............................................................................+++++
..................................+++++
writing new private key to 'newkey.pem'
Enter PEM pass phrase:
Verifying - Enter PEM pass phrase:
-----
You are about to be asked to enter information that will be incorporated
into your certificate request.
What you are about to enter is what is called a Distinguished Name or a DN.
There are quite a few fields but you can leave some blank
For some fields there will be a default value,
If you enter '.', the field will be left blank.
-----
Country Name (2 letter code) [AU]:id
State or Province Name (full name) [Some-State]:jawa barat
Locality Name (eg, city) []:bekasi
Organization Name (eg, company) [Internet Widgits Pty Ltd]:mediatama
Organizational Unit Name (eg, section) []:networking
Common Name (e.g. server FQDN or YOUR name) []:router2.unixexplore.com
Email Address []:[email protected]
Please enter the following 'extra' attributes
to be sent with your certificate request
A challenge password []:
An optional company name []:
==> 0
====
Request is in newreq.pem, private key is in newkey.pem
root@router2:/usr/local/openssl/certs #
Using the "copy" command, copy all the certificates to the /usr/local/openssl/certs directory, use the following script to do this.
root@router2:/usr/local/openssl/certs # cp newreq.pem router2.unixexplore.com-cert.pem
root@router2:/usr/local/openssl/certs # cp newkey.pem router2.unixexplore.com-encrypted-key.pem
root@router2:/usr/local/openssl/certs # cp demoCA/cacert.pem ./unixexplore.com-CAcert.pem
root@router2:/usr/local/openssl/certs # cp demoCA/private/cakey.pem ./unixexplore.com-encrypted-CAkey.pem
To remove encryption and make unencrypted files readable only by root, use the following script.
root@router2:/usr/local/openssl/certs # openssl rsa -in router2.unixexplore.com-encrypted-key.pem -out router2.unixexplore.com-unencrypted-key.pem
Enter pass phrase for router2.unixexplore.com-encrypted-key.pem:
writing RSA key
root@router2:/usr/local/openssl/certs # chmod 400 router2.unixexplore.com-unencrypted-key.pem
Now we will export the CA certificate or root certificate so that it can be installed on the system that will use your SSL Certificate. This is necessary to eliminate the Untrusted SSL Root Certificate Warning message. This message appears to warn the end user that there is a potential problem with the SSL Certificate.
It is harder to detect a real SSL session hijacking if this unnecessary warning is not removed. Most client systems (Windows and Mac OS X) recognize SSL certificate files encoded in the DER (Distinguished Encoding Rules) binary format. To convert a text-based PEM (Privacy Enhanced Mail) certificate to DER format, type the following command.
root@router2:/usr/local/openssl/certs # openssl x509 -in unixexplore.com-CAcert.pem -inform PEM -out unixexplore.com-CAcert.cer -outform DER
You can send a DER encoded certificate via email with this command.
root@router2:/usr/local/openssl/certs # uuencode unixexplore.com-CAcert.cer unixexplore.com-CAcert.cer | mail -s "Subject" [email protected]
CAcert is a certificate authority that issues free SSL Certificates. If you are new to SSL Certificates, this site is a great place to learn about the SSL Certificate signing process. You can create a certificate signing request as described in this guide and have it signed by CAcert.
Certificates signed by CAcert have limited support; most web browsers do not include their root certificates in their database of trusted CAs. However, CAcert root certificates are included in FreeBSD and some Linux distributions.
